Product Description:
The ADN/AEN compact cylinders are more than just standard equipment. These cylinders are designed to comply with or be based on the ISO 21287 standard, depending on the piston diameter. Thanks to the large number of variants, the ADN/AEN series offers a wide range of applications, making them not only powerful but also convenient for any situation.
The modular product system allows the variants to be configured according to specific requirements. The compact design means that the ADN/AEN cylinders can fit almost any space, while still providing power and accuracy.
The ADN/AEN compact cylinders are powerful, convenient, and reliable. The integrated cushioning system is a testament to their power, absorbing residual energy and providing a long service life thanks to exceptional cushioning characteristics and low friction values.
Installation is also convenient with the comprehensive range of mounting accessories available for all types of installation. The wide range of variants and contactless position sensing thanks to proximity switches ensure maximum flexibility and accuracy.
Festo has been manufacturing cylinders for over 40 years, making them a reliable partner in the industry. With optimised manufacturing methods and patented technology, it's no surprise that the ADN/AEN series cylinders are a popular choice for a range of applications.
| ADN-12-5-I-P-A | 536211 | ADN-12-5-A-P-A | 536204 |
| ADN-12-10-I-P-A | 536212 | ADN-12-10-A-P-A | 536205 |
| ADN-12-15-I-P-A | 536213 | ADN-12-15-A-P-A | 536206 |
| ADN-12-20-I-P-A | 536214 | ADN-12-20-A-P-A | 536207 |
| ADN-12-25-I-P-A | 536215 | ADN-12-25-A-P-A | 536208 |
| ADN-12-30-I-P-A | 536216 | ADN-12-30-A-P-A | 536209 |
| ADN-12-40-I-P-A | 536217 | ADN-12-40-A-P-A | 536210 |
| | | | |
| ADN-16-5-I-P-A | 536226 | ADN-16-5-A-P-A | 536219 |
| ADN-16-10-I-P-A | 536227 | ADN-16-10-A-P-A | 536220 |
| ADN-16-15-I-P-A | 536228 | ADN-16-15-A-P-A | 536221 |
| ADN-16-20-I-P-A | 536229 | ADN-16-20-A-P-A | 536222 |
| ADN-16-25-I-P-A | 536230 | ADN-16-25-A-P-A | 536223 |
| ADN-16-30-I-P-A | 536231 | ADN-16-30-A-P-A | 536224 |
| ADN-16-40-I-P-A | 536232 | ADN-16-40-A-P-A | 536225 |
| ADN-16-50-I-P-A | 536341 | ADN-16-50-A-P-A | 536331 |
| | | | |
| ADN-20-5-I-P-A | 536242 | ADN-20-5-A-P-A | 536234 |
| ADN-20-10-I-P-A | 536243 | ADN-20-10-A-P-A | 536235 |
| ADN-20-15-I-P-A | 536244 | ADN-20-15-A-P-A | 536236 |
| ADN-20-20-I-P-A | 536245 | ADN-20-20-A-P-A | 536237 |
| ADN-20-25-I-P-A | 536246 | ADN-20-25-A-P-A | 536238 |
| ADN-20-30-I-P-A | 536247 | ADN-20-30-A-P-A | 536239 |
| ADN-20-40-I-P-A | 536248 | ADN-20-40-A-P-A | 536240 |
| ADN-20-50-I-P-A | 536249 | ADN-20-50-A-P-A | 536241 |
| ADN-20-60-I-P-A | 536362 | ADN-20-60-A-P-A | 536352 |
| | | | |
| ADN-25-5-I-P-A | 536259 | ADN-25-5-A-P-A | 536251 |
| ADN-25-10-I-P-A | 536260 | ADN-25-10-A-P-A | 536252 |
| ADN-25-15-I-P-A | 536261 | ADN-25-15-A-P-A | 536253 |
| ADN-25-20-I-P-A | 536262 | ADN-25-20-A-P-A | 536254 |
| ADN-25-25-I-P-A | 536263 | ADN-25-25-A-P-A | 536255 |
| ADN-25-30-I-P-A | 536264 | ADN-25-30-A-P-A | 536256 |
| ADN-25-40-I-P-A | 536265 | ADN-25-40-A-P-A | 536257 |
| ADN-25-50-I-P-A | 536266 | ADN-25-50-A-P-A | 536258 |
| ADN-25-60-I-P-A | 536383 | ADN-25-60-A-P-A | 536373 |
| | | | |
| ADN-32-5-I-P-A | 536278 | ADN-32-5-A-P-A | 536268 |
| ADN-32-10-I-P-A | 536279 | ADN-32-10-A-P-A | 536269 |
| ADN-32-15-I-P-A | 536280 | ADN-32-15-A-P-A | 536270 |
| ADN-32-20-I-P-A | 536281 | ADN-32-20-A-P-A | 536271 |
| ADN-32-25-I-P-A | 536282 | ADN-32-25-A-P-A | 536272 |
| ADN-32-30-I-P-A | 536283 | ADN-32-30-A-P-A | 536273 |
| ADN-32-40-I-P-A | 536284 | ADN-32-40-A-P-A | 536274 |
| ADN-32-50-I-P-A | 536285 | ADN-32-50-A-P-A | 536275 |
| ADN-32-60-I-P-A | 536286 | ADN-32-60-A-P-A | 536276 |
| ADN-32-80-I-P-A | 536287 | ADN-32-80-A-P-A | 536277 |
| | | | |
| ADN-40-5-I-P-A | 536299 | ADN-40-5-A-P-A | 536289 |
| ADN-40-10-I-P-A | 536300 | ADN-40-10-A-P-A | 536290 |
| ADN-40-15-I-P-A | 536301 | ADN-40-15-A-P-A | 536291 |
| ADN-40-20-I-P-A | 536302 | ADN-40-20-A-P-A | 536292 |
| ADN-40-25-I-P-A | 536303 | ADN-40-25-A-P-A | 536293 |
| ADN-40-30-I-P-A | 536304 | ADN-40-30-A-P-A | 536294 |
| ADN-40-40-I-P-A | 536305 | ADN-40-40-A-P-A | 536295 |
| ADN-40-50-I-P-A | 536306 | ADN-40-50-A-P-A | 536296 |
| ADN-40-60-I-P-A | 536307 | ADN-40-60-A-P-A | 536297 |
| ADN-40-80-I-P-A | 536308 | ADN-40-80-A-P-A | 536298 |
| | | | |
| ADN-50-5-I-P-A | 536320 | ADN-50-5-A-P-A | 536310 |
| ADN-50-10-I-P-A | 536321 | ADN-50-10-A-P-A | 536311 |
| ADN-50-15-I-P-A | 536322 | ADN-50-15-A-P-A | 536312 |
| ADN-50-20-I-P-A | 536323 | ADN-50-20-A-P-A | 536313 |
| ADN-50-25-I-P-A | 536324 | ADN-50-25-A-P-A | 536314 |
| ADN-50-30-I-P-A | 536325 | ADN-50-30-A-P-A | 536315 |
| ADN-50-40-I-P-A | 536326 | ADN-50-40-A-P-A | 536316 |
| ADN-50-50-I-P-A | 536327 | ADN-50-50-A-P-A | 536317 |
| ADN-50-60-I-P-A | 536328 | ADN-50-60-A-P-A | 536318 |
| ADN-50-80-I-P-A | 536329 | ADN-50-80-A-P-A | 536319 |
| | | | |
| ADN-63-10-I-P-A | 536342 | ADN-63-10-A-P-A | 536332 |
| ADN-63-15-I-P-A | 536343 | ADN-63-15-A-P-A | 536333 |
| ADN-63-20-I-P-A | 536344 | ADN-63-20-A-P-A | 536334 |
| ADN-63-25-I-P-A | 536345 | ADN-63-25-A-P-A | 536335 |
| ADN-63-30-I-P-A | 536346 | ADN-63-30-A-P-A | 536336 |
| ADN-63-40-I-P-A | 536347 | ADN-63-40-A-P-A | 536337 |
| ADN-63-50-I-P-A | 536348 | ADN-63-50-A-P-A | 536338 |
| ADN-63-60-I-P-A | 536349 | ADN-63-60-A-P-A | 536339 |
| ADN-63-80-I-P-A | 536350 | ADN-63-80-A-P-A | 536340 |
| | | | |
| ADN-80-10-I-P-A | 536363 | ADN-80-10-A-P-A | 536353 |
| ADN-80-15-I-P-A | 536364 | ADN-80-15-A-P-A | 536354 |
| ADN-80-20-I-P-A | 536365 | ADN-80-20-A-P-A | 536355 |
| ADN-80-25-I-P-A | 536366 | ADN-80-25-A-P-A | 536356 |
| ADN-80-30-I-P-A | 536367 | ADN-80-30-A-P-A | 536357 |
| ADN-80-40-I-P-A | 536368 | ADN-80-40-A-P-A | 536358 |
| ADN-80-50-I-P-A | 536369 | ADN-80-50-A-P-A | 536359 |
| ADN-80-60-I-P-A | 536370 | ADN-80-60-A-P-A | 536360 |
| ADN-80-80-I-P-A | 536371 | ADN-80-80-A-P-A | 536361 |
| | | | |
| ADN100-10-I-P-A | 536384 | ADN100-10-A-P-A | 536374 |
| ADN-100-15-I-P-A | 536385 | ADN-100-15-A-P-A | 536375 |
| ADN-100-20-I-P-A | 536386 | ADN-100-20-A-P-A | 536376 |
| ADN-100-25-I-P-A | 536387 | ADN-100-25-A-P-A | 536377 |
| ADN-100-30-I-P-A | 536388 | ADN-100-30-A-P-A | 536378 |
| ADN-100-40-I-P-A | 536389 | ADN-100-40-A-P-A | 536379 |
| ADN-100-50-I-P-A | 536390 | ADN-100-50-A-P-A | 536380 |
| ADN-100-60-I-P-A | 536391 | ADN-100-60-A-P-A | 536381 |
| ADN-100-80-I-P-A | 536392 | ADN-100-80-A-P-A | 536382 |
